EPA Engine 1200kg Hightop Mini Excavator Three Cylinders Water Cool Mini Digger
HT12 Hightop mini excavator Description:
Super Power and Saving Energy
Euro 5, EPA, CE,IsO Certificate
Optional function: swing boom, retractable track
Quick and easy replacement of accessories
Multi-functions
HT12 hightop mini excavator with Kubota D722 engine, quality guaranteed, easy maintenance, excavator you deserve.
HT12 Hightop mini excavator Features:
1. Beautiful appearance,high configuration,superior performance,low fuel consumption,wide operating range.
2. reduce maintenance & operating costs liberate the workforce. Improve the mechanization, Iow investment,high return.
3. Standard configuration: one standard bucket 380mm & canopy.
4.Optional accessory: narrow bucket 200mm, plain bucket 500mm, ripper, rake, auger, break hammer, quick hitch
Hightop mini excavator Technical parameters:
| Model | HT12 |
| Weight | 1200kg |
| Digging bucket capacity | 0.025cbm/120kg |
| Bucket width | 380mm |
| Engine | Kubota D722 |
| Bore stroke | Three cylinders,water cool |
| Rated power | 10.2kw/2500r/min |
| Displacement | 6.8mlr |
| Main pump | G5-6 |
| Swing motor | China brand |
| Travelling motor | China brand USA EATON motor(optional) |
| Travel speed | 1.5kmh |
| Battery | 12V 60A |
| Main Demensions | |
| Overall dimension( LxWxH) | 2770x896x1490 mm |
| Wheelbase | 910 mm |
| Total length of track | 1230mm |
| Plattorm ground clearance | 380 mm |
| Platform back tuming radius | 784 mm |
| Chassis width | 896 mm |
| Track width | 180 mm |
| Chassls ground clearance | 132 mm |
| Track height | 320 mm |
| Operating Range | |
| Max Digging depith | 1650 mm |
| Max. Vertical dgging depth | 1375 mm |
| Max Digging height | 2610 mm |
| Max. Dumping height | 1850 mm |
| Max, Digging radius on ground | 2850 mm |
| Min. Rotation radius | 1330 mm |
| Max. Upgrade helght of bulldozer blade | 345 mm |
| Max. Digging depth of bulozer blade | 255 mm |
Applications:
HT12 hightop mini excavator is suitable for loosing soil of vegetable greenhouse,campus greening of municipal departments, digging the hole for tree planting of Fruit-land Nurseries, Concrete pavement crushing, sand-gravel material mixing, construction work in the narrow space.
